24 Head Mixing Weigher

• Can be used for 2 in 1, 3 in 1 and 4 in 1 mixing products.

• The mixed weight can be automatically compensated by the last material.

• 100 programs for multiple tasks.

• Program recovery function can reduce operation failure.

• High precision digital load cell.

• Linear amplitude can be adjusted independently.

• No products auto pause function can improve weighing stability and accuracy.

• Modular control system, AD cards no need Number, can be interchangeable.

• All the hoppers can be opened to make cleaning easily and quickly.

• Each drive board is independent, can be changed freely, even in different weighers.

• Friendly HMI, similar with mobile phone operation icons, make operation more easily and simple.

• Weighers with strong self-checking function, can realize the closed loop testing, real-time detect abnormalities in each node, and real-time display in human-machine interface.

• The software versatility, strong compatibility, different weighers using the same control system.

Separate top cone is used for two mixed formula materials.

Independent main vibrator is used to control the feeding thickness of different materials.

The integral machine frame and center base enhance the rigidity and strength of the machine, making the weighing more accurate.

New actuator design reduces the mechanical vibration and improves the accuracy of load cell.

Accurately and continuously mix and weigh different products of different weights.
CBW mixing scale is suitable for weighing granular materials with good fluidity, tea leaves, Chinese herbal medicine, seeds, beans, coffee beans, chocolate beans, nuts, monosodium glutamate, chicken essence, etc. By weighing different weights, the weights of different materials can be complementary, so as to control the accuracy of the total weight. Two or more materials are fed to their respective main vibration plates, weighed in combination according to their respective target weights, and then put into the same bag, bottle, carton or other type of container.
